Three-phase Vienna rectifier

Three-phase power is often used by high power industrial applications. To improve overall quality and minimize harmonic currents power factor correction (PFC) is often required as many of the forward loads are DC – for example electric vehicle (EV) battery charging. The Vienna rectifier power topology is often the preferred choice as it operates in continuous conduction mode (CCM), has inherent multilevel switching (three level), and reduced voltage stress on the power devices.

Block diagram

設計考慮因素

  • 開始采用PWM驅動無刷直流電機控制
  • 電機驅動MOSFET必須以低RDSon和良好的熱阻抗來滿足峰值高電流需求
  • 如果過載情況會降低電池和柵極電壓，則可能需要具有強線性模式性能的MOSFET來提供反向電池保護
  • MOSFET可能需要滿足UL2595等的具體間距要求
  • 為小尺寸優化的電荷平衡MOSFET，通常裝在可移動電池組中——每個電池一個

MOSFET and GaN FET Handbook

Drawing on over 20 years’ of experience, the MOSFET and GaN FET Application Handbook: A Power Design Engineer’s Guide brings together a comprehensive set of learning and reference materials relating to the use of MOSFETs and GaN FETs in real world systems.

Download your copy today

Nexperia’s CFP2-HP delivers high thermal performance in a small footprint

Nexperia’s CFP2-HP delivers high thermal performance in a small footprint

As automotive, mobile and other applications becoming increasingly miniature with more components needing to fit on a PCB, smaller packages are required to save space. Nexperia’s CFP2-HP meets this challenge and delivers high performance for the most challenging designs.
