配電阻晶體管(RET)

利用節省空間和成本的解決方案減少器件數量并簡化電路設計

通過將晶體管和它們的配套電阻相結合，RET提供了能夠節省空間和成本的出色解決方案。我們提供大約400種產品，您可以找到適合您應用的產品。在我們的產品組合中，您可以找到電阻組合各不相同的許多單通道和雙通道RET。此外，還有各種SMD和引腳封裝供您選擇。

主要特性和優勢

  • ± 10%電阻比容差
  • 降低貼片成本
  • 內置偏置電阻
  • 減少器件數量
  • 100 mA、500 mA和最高600 mA的輸出電流能力
  • 簡化電路設計

關鍵應用

  • 控制IC輸入
  • 數字系統
  • 開關負載

最新新聞和博客

  • 博客文章
1月 4, 2023

了解RET的開關特性

參數搜索

Resistor Equipped Transistors (RETs)
數據加載中，請稍候...
參數搜索不可用。

產品

型號 描述 狀態 快速訪問
PDTA113E series PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm ACT
PDTA113EM PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTA113ET PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTA113EU PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PDTA113Z series PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm ACT
PDTA113ZM PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm Production
PDTA113ZT PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm Production
PDTA113ZU PNP resistor-equipped transistors; R1 = 1 kOhm, R2 = 10 kOhm Production
PDTA114T series PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open ACT
PDTA114TM PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTA114TT PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTA114TU PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTA114Y series PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ ACT
PDTA114YM PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YT PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA114YU PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA115E series PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm ACT
PDTA115EM PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115EMB PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115ET PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115EU PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115EU-Q PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTA115T series PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open ACT
PDTA115TM PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTA115TT PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTA115TU PNP resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTA123E series PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm ACT
PDTA123EM PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123EMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123ET PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123EU PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123EU-Q PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA123J series PNP resistor-equipped transistors; R1 = 2.2 kΩ, R2 = 47 kΩ ACT
PDTA123JM PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123JT PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123JU PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA123T series PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PDTA123TM PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTA123TT PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTA123TU PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTA123Y series PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm ACT
PDTA123YM PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm Production
PDTA123YT PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm Production
PDTA123YU PNP resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm Production
PDTA124E PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ ACT
PDTA124EM PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124ET 50 V, 100 mA PNP resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTA124EU PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA124T series PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PDTA124TM PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTA124TT PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTA124TU PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTA124X series PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm ACT
PDTA124XM PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA124XT PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA124XU PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA143/114/124/144EQA series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143E series PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ ACT
PDTA143EM PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143ET PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143EU PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA143T series PNP resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open ACT
PDTA143TM PNP resistor-equipped transistor;?R1?=?4.7?kΩ,?R2?=?open Production
PDTA143TT PNP resistor-equipped transistor;?R1?=?4.7?kΩ,?R2?=?open Production
PDTA143X series PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ ACT
PDTA143XM PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143XT PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143XU PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA143X/123J/143Z/114YQA series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA123JQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143X_TO_124XQB series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA123JQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA124XQB 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143ZQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143X_TO_124XQC Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA123JQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124XQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143X_TO_124XQC-Q Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114YQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA123JQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124XQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143XQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143Z series PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ ACT
PDTA143ZM 50 V, 100 mA PNP resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PDTA143ZMB PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PDTA143ZQA 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143ZQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143ZQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143ZT 50 V, 100 mA PNP resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PDTA143ZT-Q 50 V, 100 mA PNP resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PDTA143ZU 50 V, 100 mA PNP resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PDTA143_114_124_144EQB series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA124EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA144EQB 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143_114_124_144EQC Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQC 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQC 50 V, 100 mA PNP resistor-equipped transistors EndOfLife
PDTA143_114_124_144EQC-Q Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143_114_124_144EQC-Q Series 50 V, 100 mA PNP resistor-equipped transistors ACT
PDTA114EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA124EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA143EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144EQC-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA144E series PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ ACT
PDTA144EM PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144ET PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144EU PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA144T series PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open ACT
PDTA144TM PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTA144TT PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTA144TU PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTA144V series PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm ACT
PDTA144VM PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTA144VT PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTA144VU PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTA144W series PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PDTA144WM PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTA144WT PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTA144WU PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTB113Z_123Y_143XQA_SER 50 V, 500 mA PNP resistor-equipped transistors ACT
PDTB113ZQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB123YQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB143XQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB113_123_143_114EQA_SER 50 V, 500 mA PNP resistor-equipped transistors ACT
PDTB113EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB114EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB123EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB143EQA 50 V, 500 mA PNP resistor-equipped transistors Production
PDTB1xxxT series 500 mA, 50 V PNP resistor-equipped transistors ACT
PDTB114ET 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143ET 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143XT 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB1xxxU series 500 mA, 50 V PNP resistor-equipped transistors ACT
PDTB113EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB113ZU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB114EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB114EU-Q 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB123EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB123YU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143EU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTB143XU 50 V, 500 mA PNP resistor-equipped transistor Production
PDTC114T series NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open ACT
PDTC114TM NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTC114TT NPN resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PDTC114TU NPN resistor-equipped transistor; R1 = 10 kOhm, R2 = open Production
PDTC115E series NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm ACT
PDTC115EM 50 V, 20 mA NPN resistor-equipped transistor; R1?=?100?kΩ,?R2?=?100?kΩ Production
PDTC115ET 50 V, 20 mA NPN resistor-equipped transistor; R1?=?100?kΩ,?R2?=?100?kΩ Production
PDTC115EU 50 V, 20 mA NPN resistor-equipped transistor; R1?=?100?kΩ,?R2?=?100?kΩ Production
PDTC115T series NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open ACT
PDTC115TM NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTC115TT NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTC115TU NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = open Production
PDTC123E series NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm ACT
PDTC123EM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
PDTC123ET 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
PDTC123EU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
PDTC123T series NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PDTC123TM NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC123TT NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC123TU NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC123Y series NPN resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm ACT
PDTC123YM NPN resistor-equipped transistor; R1 = 2.2 k?, R2 = 10 k? Production
PDTC123YU NPN resistor-equipped transistor; R1 = 2.2 k?, R2 = 10 k? Production
PDTC124T series NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PDTC124TM NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTC124TT NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTC124TU NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PDTC124X series NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm ACT
PDTC124XM NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm Production
PDTC124XT 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?47?kΩ Production
PDTC124XU NPN resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm Production
PDTC143/114/124/144EQA series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144EQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143T series NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open ACT
PDTC143TM NPN resistor-equipped transistor;?R1?=?4.7?kΩ,?R2?=?open Production
PDTC143TT NPN resistor-equipped transistors;?R1?=?4.7?kΩ,?R2?=?open Production
PDTC143TU 50 V, 100 mA NPN resistor-equipped transistor;?R1?=?4.7?kΩ,?R2?=?open Production
PDTC143X/123J/143Z/114YQA series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC123JQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZQA 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143X_TO_124XQB Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC123JQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC124XQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143XQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143ZQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143X_TO_124XQB-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC123JQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124XQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143X_TO_124XQC Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC123JQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC124XQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143XQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143ZQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143X_TO_124XQC-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114YQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC123JQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124XQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQB Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQB 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143EQB 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC144EQB 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQB-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144EQB-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQC Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC124EQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC143EQC 50 V, 100 mA NPN resistor-equipped transistors EndOfLife
PDTC144EQC 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143_114_124_144EQC-Q Series 50 V, 100 mA NPN resistor-equipped transistors ACT
PDTC114EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC124EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC143EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144EQC-Q 50 V, 100 mA NPN resistor-equipped transistors Production
PDTC144T series NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open ACT
PDTC144TM NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTC144TT NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTC144TU NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PDTC144V series NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm ACT
PDTC144VM NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTC144VT NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTC144VU NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 10 kOhm Production
PDTC144W series NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PDTC144WM NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTC144WT 50 V, 100 mA NPN resistor-equipped transistor;?R1?=?47?kΩ,?R2?=?22 kΩ Production
PDTC144WU NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PDTD123Y series NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 10 kOhm ACT
PDTD123YQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD123YT 50 V, 500 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PDTD123YT-Q 50 V, 500 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PDTD123YU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD1xxxT series 500 mA, 50 V NPN resistor-equipped transistors ACT
PDTD114ET 50 V, 500 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PDTD143ET 50 V, 500 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7?kΩ Production
PDTD143ET-Q 500 mA, 50 V NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7?kΩ Production
PDTD143XT 50 V, 500 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?10?kΩ Production
PDTD1xxxU series 500 mA, 50 V NPN resistor-equipped transistors ACT
PDTD113EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD113ZU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD114EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD114EU-Q 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD123EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD123YU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD143EU 50 V, 500 mA NPN resistor-equipped transistor Production
PDTD143XU 50 V, 500 mA NPN resistor-equipped transistor Production
PEMB13; PUMB13 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ ACT
PEMB13 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PEMB14; PUMB14 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open ACT
PUMB14 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = open Production
PEMB15; PUMB15 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ ACT
PUMB15 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PEMB16; PUMB16 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm ACT
PUMB16 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = 47 kOhm Production
PEMB17; PUMB17 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PEMB17 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm EndOfLife
PUMB17 PNP/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PEMB18; PUMB18 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ ACT
PEMB18 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ EndOfLife
PUMB18 PNP/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PEMB19; PUMB19 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PEMB19 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open EndOfLife
PUMB19 PNP/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PEMB1; PUMB1 PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ ACT
PEMB1 PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ EndOfLife
PUMB1 PNP/PNP resistor-equipped transistors; R1 = 22 kΩ, R2 = 22 kΩ Production
PEMB30; PUMB30 PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PEMB30 PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open EndOfLife
PUMB30 PNP/PNP double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PEMB4; PUMB4 PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open ACT
PEMB4 PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open EndOfLife
PUMB4 PNP/PNP resistor-equipped transistors; R1 = 10 kOhm, R2 = open Production
PEMD12; PUMD12 NPN/PNP resistor-equipped transistors; R1 = 47 kΩ, R2 = 47 kΩ ACT
PUMD12 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PEMD17; PUMD17 NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PEMD17 NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm EndOfLife
PUMD17 NPN/PNP resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PEMD18; PUMD18 NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ ACT
PEMD18 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?10?kΩ EndOfLife
PEMD19; PUMD19 NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open ACT
PEMD19 NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open EndOfLife
PUMD19 NPN/PNP resistor-equipped transistors; R1 = 22 kOhm, R2 = open Production
PEMH17; PUMH17 NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm ACT
PEMH17 NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm EndOfLife
PUMH17 NPN/NPN resistor-equipped transistors; R1 = 47 kOhm, R2 = 22 kOhm Production
PEMH24; PUMH24 NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm ACT
PEMH24 NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm EndOfLife
PUMH24 NPN/NPN resistor-equipped transistors; R1 = 100 kOhm, R2 = 100 kOhm Production
PEMH30; PUMH30 NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open ACT
PEMH30 NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open EndOfLife
PUMH30 NPN/NPN double resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PEMH7; PUMH7 NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open ACT
PEMH7 NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open EndOfLife
PUMH7 NPN/NPN resistor-equipped transistors; R1 = 4.7 kOhm, R2 = open Production
PEMH9; PIMH9; PUMH9 NPN/NPN resistor-equipped transistors; R1 = 10?kΩ, R2 = 47?kΩ ACT
PEMH9 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?10?k?,?R2?=?47?k? Production
PIMH9 NPN/NPN resistor-equipped transistors; R1?=?10?k?,?R2?=?47?k? Production
PUMH9 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?10?k?,?R2?=?47?k? Production
PUMH9-Q 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?10?k?,?R2?=?47?k? Production
NHDTA124ET 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTC144EU 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMH1 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHDTC124ET 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTA123JT 80 V, 100 mA PNP resistor-equipped transistors Production
PBRN113ES EndOfLife
PBRP113ZT 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PBRP123ET 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PEMB3 50 V, 100 mA PNP/PNP Resistor-Equipped Transistor; R1?=?4.7?kΩ,?R2?=?open Production
NHUMD12 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
PBRN113ZT 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PBRP113ET 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PDTC124EU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTC114YMB NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC124ET 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PEMD13 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PEMH20 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 k?, R2 = 2.2 k? Production
PEMB11 PNP/PNP resistor-equipped transistor; R1??=?10?k?,?R2?=?10?k? Production
PEMD14 50 V, 100 mA NPN/PNP resistor-equipped transistor; R1?=?47?k?,?R2?=?open Production
NHDTC144ET 80 V, 100 mA NPN resistor-equipped transistors Production
PBRN123ET 40 V, 600 mA NPN PB RET; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
PEMD4 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?open Production
PEMD24 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1?=?100?k?, R2?=?100 k? Production
PDTA114EU 50 V, 100 mA PNP resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PDTB123ET PNP 500 mA, 50 V resistor-equipped transistor; R1 = 2.2 kOhm, R2 = 2.2 kOhm Production
PDTA114ET 50 V, 100 mA PNP resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PBRN113ET 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PEMH15 NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTD123EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD143EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD143XQA 50 V, 500 mA NPN resistor-equipped transistors Production
PDTD113EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PBRN123YT 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PEMH14 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?open Production
NHDTA144ET 80 V, 100 mA PNP resistor-equipped transistors Production
PDTC144ET 50 V, 100 mA NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?47 kΩ Production
PDTC144EU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?47 kΩ Production
PEMD12 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PEMD30 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?open Production
PEMD2 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTD113ZT 50 V, 500 mA NPN resistor-equipped transistor; R1?=?1?kΩ,?R2?=?10?kΩ Production
PDTC114EU NPN resistor-equipped transistors;?R1?=?10?kΩ,?R2?=?10?kΩ Production
PEMD48 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ and R1 = 2.2 kΩ, R2 = 47 kΩ Production
PEMH18 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTD113ET NPN 500 mA, 50 V resistor-equipped transistors; R1 = 1 kOhm, R2 = 1 kOhm Production
PBRP123YT 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTD113ZQA 50 V, 500 mA NPN resistor-equipped transistors Production
NHUMD3 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
PEMH19 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?open Production
PEMB9 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PEMB20 50 V, 100 mA PNP/PNP resistor-equipped transistor; R1?=?2.2?k?,?R2?=?2.2?k? Production
PEMH1 NPN/NPN resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
NHDTC114ET 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMH2 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMH11 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
PDTB123YT 50 V, 500 mA PNP resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PDTC114YT 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PIMD3 NPN/PNP resistor-equipped transistors; R1?=?10?kΩ,?R2?=?10?kΩ Production
PDTC123JT 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTC143ET 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7 ?kΩ Production
PDTA143TU PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PEMD15 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?4.7?kΩ Production
PDTC123YT NPN resistor-equipped transistor; R1 = 2.2 k?, R2 = 10 k? Production
PDTB123TT PNP 500 mA, 50 V resistor-equipped transistor; R1 = 2.2 kOhm, R2 = open Production
PDTC123JU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTC143EU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7 ?kΩ Production
PEMD16 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?47?kΩ Production
PDTB113ZT PNP 500 mA, 50 V resistor-equipped transistor; R1?=?1?kΩ,?R2?=?10?kΩ Production
PDTD114EQA 50 V, 500 mA NPN resistor-equipped transistors Production
PBRN113EK EndOfLife
PEMH4 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?10?k?,?R2?=?open Production
PDTC143ZU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PEMH10 50 V, 100 mA NPN/NPN resistor-equipped double?transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PEMH2 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PEMD10 NPN/PNP double Resistor-Equipped Transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PEMD6 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1?=?4.7?kΩ,?R2?=?open Production
PEMH13 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=??47?kΩ Production
PEMB24 50 V, 20 mA PNP/PNP resistor-equipped transistor; R1?=?100?k?,?R2?=?100?k? Production
PEMD3 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PEMB2 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PDTC114YU 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PDTC114EM NPN resistor-equipped transistors;?R1?=?10?kΩ,?R2?=?10?kΩ Production
PEMB10 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTB113ET PNP 500 mA, 50 V resistor-equipped transistor; R1 = 1 kOhm, R2 = 1 kOhm Production
PQMH13 NPN/NPN resistor-equipped double transistor; R1?=?4.7?k?,?R2?=?47?k? Production
PRMD16 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PUMB13 PNP/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?47?kΩ Production
PUMD10 NPN/PNP double Resistor-Equipped Transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PUMD3 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PUMH10 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTC114YM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PEMH11 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 10 k?, R2 = 10 k? Production
PEMH16 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?47 kΩ Production
PEMD9 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
NHUMD2 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
PEMD20 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 k?, R2 = 2.2 k? Production
PEMF21 12 V PNP loadswitch EndOfLife
PUMD2 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PUMD4 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?open Production
PUMH1 NPN/NPN resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PUMD24 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 k?, R2 = 100 k? Production
PUMD6H 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open EndOfLife
PUMD13 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?47?kΩ Production
PUMB11 50 V, 100 mA PNP/PNP resistor-equipped double transistors; R1?=?10?k?,?R2?=?10?k? Production
PUMD15 NPN/PNP resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PUMD48 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ?and?R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PUMH11 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PUMB2 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PUMD9 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PUMD6 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1?=?4.7?kΩ,?R2?=?open Production
PUMB3H 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open EndOfLife
PUMH13 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1=?4.7?kΩ,?R2?=?47?kΩ Production
PUMH15 NPN/NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PUMH14 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?open Production
PIMP32 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PIMC32 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor (RET); R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PUMH2 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PUMD16 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?47?kΩ Production
PIMC31PA 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1?= 1?kΩ,?R2?=?10 kΩ Production
PIMN31PA 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1?= 1?kΩ,?R2?=?10 kΩ Production
PUMH7H 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open EndOfLife
PIMN32 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor (RET); R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PIMN32PA 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1?= 2.2?kΩ,?R2?=?10 kΩ Production
PDTC123YQB 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?k?,?R2:?10?k? Production
PIMP31 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1?=?1?kΩ,?R2?=?10?kΩ Production
PIMC32PA 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTA123YQB 50 V, 100 mA PNP resistor-equipped transistor; R1?=?2.2?k?,?R2:?10?k? Production
PIMP31PA 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1?= 1?kΩ,?R2?=?10 kΩ Production
PIMP32PA 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1?= 2.2?kΩ,?R2?=?10 kΩ Production
PDTC114ET 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
NHDTA114YT 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA143ZT 80 V, 100 mA PNP resistor-equipped transistors Production
PIMC31 500 mA, 50 V NPN/PNP double resistor-equipped transistor; R1 = 1 k?, R2 = 10 k? Production
NHDTA124EU 80 V, 100 mA PNP resistor-equipped transistors Production
NHUMD10 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHDTC123JU 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMD9 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMB11 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB9 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHDTA123JU 80 V, 100 mA PNP resistor-equipped transistors Production
NHUMB10 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMH9 80 V, 100 mA NPN/NPN resistor-equipped double transistor Production
NHUMB2 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHDTA114ET 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114EU 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA144EU 80 V, 100 mA PNP resistor-equipped transistors Production
PDTA113ZMB PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA124TMB PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = open Production
PDTA124XMB PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTA114YMB PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTA143XMB PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA144EMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTC143EM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7 ?kΩ Production
NHDTC143ZU 80 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XU NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA113EMB PNP resistor-equipped transistor; R1 = 1 kΩ, R2 = 1 kΩ Production
NHDTC124EU 80 V, 100 mA NPN resistor-equipped transistors Production
PDTC143XMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTC124TMB NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = open Production
PQMH2 NPN/NPN resistor-equipped transistors; R1?=?47?k?,?R2?=?47?k? Production
PQMD2 NPN/PNP resistor-equipped transistors; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTC144EMB 50 V, 100 mA NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTA123JMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA114TMB PNP resistor-equipped transistor; R1 = 10 kΩ, R2 = open Production
PIMD2 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTD123ET NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = 2.2 kOhm Production
PDTC144EM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?47 kΩ Production
NHDTA143ZU 80 V, 100 mA PNP resistor-equipped transistors Production
PDTC143XM NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
NHUMB13 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHDTC143ZT 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMD13 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
PDTC143XT NPN resistor-equipped transistors; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PDTA123YMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
NHUMH13 80 V, 100 mA NPN/NPN resistor-equipped double transistor Production
NHDTC114YT 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114EU 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YU 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMH10 80 V, 100 mA NPN/NPN resistor-equipped double transistor Production
PDTA143TMB PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTA144TMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
NHDTA114YU 80 V, 100 mA PNP resistor-equipped transistors Production
PDTA123TMB PNP resistor-equipped transistor; R1 = 2.2 kΩ, R2 = open Production
PDTC123TMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = open Production
PDTC115TMB NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = open Production
NHUMB1 80 V, 100 mA PNP/PNP resistor-equipped double transistors Qualification
PDTC143EMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTC143ZT 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PDTA124EMB PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTC144VMB NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 10 kΩ Production
PDTC123JMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 47 kΩ Production
PDTA144VMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 10 kΩ Production
PDTA114EM 50 V, 100 mA PNP resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PDTC144WMB NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC123JM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTC115EMB NPN resistor-equipped transistor; R1 = 100 kΩ, R2 = 100 kΩ Production
PDTD123TT NPN 500 mA, 50 V resistor-equipped transistors; R1 = 2.2 kOhm, R2 = open Production
PDTC144TMB NPN resistor-equipped transistor; R1 = 47 kΩ, R2 = open Production
PDTA114EMB 50 V, 100 mA PNP resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PDTC114EMB NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = 10 kΩ Production
PDTC123EMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTC143ZM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PQMD16 NPN/PNP resistor-equipped transistors; R1?=?22?k?,?R2?=?47?k? Production
PQMH11 NPN/NPN resistor-equipped transistors; R1?=?10?k?,?R2?=?10?k? Production
PRMD13 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PUMD30 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?open Production
PQMD12 NPN/PNP resistor-equipped transistors; R1?=?47?kΩ,?R2?=?47?kΩ Production
PQMB11 PNP/PNP resistor-equipped transistors; R1?=?10?k?,?R2?=?10?k? Production
PUMH4 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?open Production
PQMH9 NPN/NPN resistor-equipped transistors; R1?=?10?k?,?R2?=?47?k? Production
PRMH13 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PQMD13 NPN/PNP resistor-equipped transistors; R1?=?4.7?k?,?R2?=?47?k? Production
PRMH9 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PRMH2 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PRMD2 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
NHDTC123JT 80 V, 100 mA NPN resistor-equipped transistors Production
PDTA143EMB PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 4.7 kΩ Production
PDTA144WMB PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 22 kΩ Production
PDTC124EMB NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 22 kΩ Production
PDTA115TMB PNP resistor-equipped transistor; R1 = 100 kΩ, R2 = open Production
PDTC124EM 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTC114TMB NPN resistor-equipped transistor; R1 = 10 kΩ, R2 = open Production
PDTC123YMB NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTC143TMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
PDTC124XMB NPN resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC143ZMB NPN resistor-equipped transistor; R1 = 4.7 kΩ, R2 = 47 kΩ Production
PUMD20 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1 = 2.2 k?, R2 = 2.2 k? Production
PIMN31 500 mA, 50 V NPN/NPN double resistor-equipped transistor; R1 = 1 kOhm, R2 = 10 kOhm Production
PUMH16 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?47 kΩ Production
PQMD10 NPN/PNP resistor-equipped transistors; R1?=?2.2?k?,?R2?=?47?k? Production
PQMD3 NPN/PNP resistor-equipped transistors; R1?=?10?k?,?R2?=?10?k? Production
PRMB11 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistors (RET) Production
PRMD3 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PQMH10 NPN/NPN resistor-equipped transistors; R1?=?2.2?k?,?R2?=?47?k? Production
PRMH10 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PUMH19 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?open Production
PUMB9 PNP/PNP double Resistor-Equipped Transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PUMB10 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PUMH18 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 4.7 kΩ, R2 = 10 kΩ Production
PRMH11 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistors (RET) Production
PBRP113ET-Q 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PUMB3 50 V, 100 mA PNP/PNP resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?open Production
PUMD18 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?10?kΩ Production
PUMD14 50 V, 100 mA NPN/PNP resistor-equipped transistor; R1?=?47?k?,?R2?=?open Production
PBRN123ET-Q 40 V, 600 mA NPN PB RET; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
PUMH7H-Q 50 V, 100 mA NPN/NPN Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open Production
PRMD10 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PUMD6H-Q 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open Production
PRMD12 50 V, 100 mA NPN/PNP Resistor-Equipped double Transistors (RET) Production
PBRP123ET-Q 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTB123YT-Q 50 V, 500 mA PNP resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PBRP113ZT-Q 40 V, 600 mA PNP PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PDTA143EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PUMD10-Q NPN/PNP double Resistor-Equipped Transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTD113ZT-Q NPN 500 mA, 50 V resistor-equipped transistor; R1?=?1?kΩ,?R2?=?10?kΩ Production
PUMH20 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1 = 2.2 k?, R2 = 2.2 k? Production
PUMD15-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?4.7?kΩ Production
PUMH2-Q 50 V, 100 mA NPN/NPN resistor-equipped double?transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PUMF12 PNP general purpose transistor; NPN resistor-equipped transistor EndOfLife
PDTA114EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PUMF11 NPN resistor-equipped transistor; PNP general purpose transistor EndOfLife
PDTA144EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PUMB20 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
PUMH10-Q NPN/NPN resistor-equipped double transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PDTA143XQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PUMB24 50 V, 20 mA PNP/PNP resistor-equipped transistor; R1?=?100?k?,?R2?=?100?k? Production
PUMD4-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?open Production
PUMD9-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PIMN32-Q 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor (RET); R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PDTC144ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?47 kΩ Production
PDTA124EQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTC143ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7 ?kΩ Production
PIMP31-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1?=?1?kΩ,?R2?=?10?kΩ Production
PUMD3-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PUMB3H-Q 50 V, 100 mA PNP/PNP Resistor-Equipped double Transistor; R1 = 4.7 kΩ, R2 = open Production
PUMD13-Q NPN/PNP resistor-equipped double transistor; R1?=?4.7?kΩ,?R2?=?47?kΩ Production
PDTC124EU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PUMD2-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PUMD16-Q 50 V, 100 mA NPN/PNP resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?47?kΩ Production
PDTA124XQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PUMD12-Q NPN/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47 kΩ Production
PDTC143EU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?4.7 ?kΩ Production
PIMP31PAS-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1?= 1?kΩ,?R2?=?10 kΩ Production
PDTC114YT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PIMP32-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor (RET); R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PDTA123YQB-Q 50 V, 100 mA PNP resistor-equipped transistor; R1?=?2.2?k?,?R2:?10?k? Production
PUMH13-Q NPN/NPN double Resistor-Equipped Transistor (RET); R1=?4.7?kΩ,?R2?=?47?kΩ Production
PBRP123YT-Q 40 V, 600 mA PNP PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PDTA123JQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA114YQB-Q 50 V, 100 mA PNP resistor-equipped transistors Production
PDTA114ET-Q 50 V, 100 mA PNP resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PBRN113ET-Q 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 1 kΩ Production
PDTC144EU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?47 kΩ Production
PDTC114ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PUMD48-Q NPN/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ?and?R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PUMB2-Q 50 V, 100 mA PNP/PNP resistor-equipped double transistor; R1?=?47?kΩ,?R2?=?47?kΩ Production
PBRN113ZT-Q 40 V, 600 mA NPN PB RET; R1 = 1 kΩ, R2 = 10 kΩ Production
PIMN32PAS-Q 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1?= 2.2?kΩ,?R2?=?10 kΩ Production
PDTC143ZU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
PDTA124ET-Q 50 V, 100 mA PNP resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PIMC32-Q 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor (RET); R1?=?2.2?kΩ,?R2?=?10?kΩ Production
PDTC123JU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PUMB11-Q 50 V, 100 mA PNP/PNP resistor-equipped double transistors; R1?=?10?k?,?R2?=?10?k? Production
PBRN123YT-Q 40 V, 600 mA NPN PB RET; R1 = 2.2 kΩ, R2 = 10 kΩ Production
PIMP32PAS-Q 50 V, 500 mA PNP/PNP Resistor-Equipped double Transistor; R1?= 2.2?kΩ,?R2?=?10 kΩ Production
PIMN31PAS-Q 50 V, 500 mA NPN/NPN Resistor-Equipped double Transistor; R1?= 1?kΩ,?R2?=?10 kΩ Production
PUMH11-Q 50 V, 100 mA NPN/NPN resistor-equipped double transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PUMB13-Q PNP/PNP resistor-equipped double transistors; R1?=?4.7?kΩ,?R2?=?47?kΩ Production
NHDTC144EU-Q 80 V, 100 mA NPN resistor-equipped transistor Production
PDTC114YU-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?10?kΩ,?R2?=?47?kΩ Production
PUMD6-Q 50 V, 100 mA NPN/PNP Resistor-Equipped Transistor; R1?=?4.7?kΩ,?R2?=?open Production
PDTC123YQB-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?k?,?R2:?10?k? Production
PIMC32PAS-Q 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1?= 2.2?kΩ,?R2?=?10 kΩ Production
PDTC124ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTA114EU-Q 50 V, 100 mA PNP resistor-equipped transistor; R1?=?10?kΩ,?R2?=?10?kΩ Production
PDTC123YT-Q NPN resistor-equipped transistor; R1 = 2.2 k?, R2 = 10 k? Production
PUMH1-Q NPN/NPN resistor-equipped double transistor; R1?=?22?kΩ,?R2?=?22?kΩ Production
PDTC123JT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?47?kΩ Production
PQMH13-Q NPN/NPN resistor-equipped double transistor; R1?=?4.7?k?,?R2?=?47?k? Production
PUMH14-Q 50 V, 100 mA NPN/NPN resistor-equipped transistor; R1?=?47?kΩ,?R2?=?open Production
NHUMH11-Q 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
NHUMD12-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD2-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD3-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
PDTA143TU-Q PNP resistor-equipped transistor; R1 = 4.7 kΩ, R2 = open Production
NHUMH1-Q 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
PIMC31PAS-Q 50 V, 500 mA NPN/PNP Resistor-Equipped double Transistor; R1?= 1?kΩ,?R2?=?10 kΩ Production
NHUMH2-Q 80 V, 100 mA NPN/NPN resistor-equipped double transistors Production
PUMD24-Q 50 V, 20 mA NPN/PNP resistor-equipped double transistor; R1 = 100 k?, R2 = 100 k? Production
NHDTA124ET-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114ET-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA144ET-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHUMB13-Q 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB10-Q 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHUMB9-Q 80 V, 100 mA PNP/PNP resistor-equipped double transistors Production
NHDTC123JT-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YT-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC143ZT-Q 80 V, 100 mA NPN resistor-equipped transistors Production
PDTC143ZT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?4.7?kΩ,?R2?=?47 ?kΩ Production
NHDTA114YU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTC114EU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTA123JU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA143ZU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
PDTC143TT-Q 50 V, 100 mA NPN resistor-equipped transistors;?R1?=?4.7?kΩ,?R2?=?open Production
NHUMD13-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHUMD10-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
NHDTC124EU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMD9-Q 80 V, 100 mA NPN/PNP resistor-equipped double transistors Production
PDTD123ET-Q 50 V, 500 mA NPN resistor-equipped transistor; R1 = 2.2 kΩ, R2 = 2.2 kΩ Production
PDTA144ET-Q PNP resistor-equipped transistor; R1 = 47 kΩ, R2 = 47 kΩ Production
PDTB143ET-Q 50 V, 500 mA PNP resistor-equipped transistor Production
PDTC123ET-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?2.2?kΩ,?R2?=?2.2?kΩ Production
NHUMH10-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHUMH13-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTA143ZT-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA123JT-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHUMH9-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC124ET-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC123JU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC144ET-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114YU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTC114ET-Q 80 V, 100 mA NPN resistor-equipped transistors Production
PDTC144WT-Q 50 V, 100 mA NPN resistor-equipped transistor;?R1?=?47?kΩ,?R2?=?22 kΩ Production
NHDTA114YT-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTC143ZU-Q 80 V, 100 mA NPN resistor-equipped transistors Production
NHDTA144EU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA124EU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
NHDTA114EU-Q 80 V, 100 mA PNP resistor-equipped transistors Production
PDTA124XT-Q PNP resistor-equipped transistor; R1 = 22 kΩ, R2 = 47 kΩ Production
PDTC124XT-Q 50 V, 100 mA NPN resistor-equipped transistor; R1?=?22?kΩ,?R2?=?47?kΩ Production
PDTA114YU-Q PNP resistor-equipped transistors; R1 = 10 kΩ, R2 = 47 kΩ Production
PDTC115EU-Q 50 V, 20 mA NPN resistor-equipped transistor; R1?=?100?kOhm,?R2?=?100?kOhm Production
Visit our documentation center for all documentation

Application note (1)
文件名稱 標題 類型 日期
AN90024.pdf Resistor Equipped Transistors (RETs): Key parameters and application insights Application note 2021-08-03

Brochure (1)
文件名稱 標題 類型 日期
Nexperia_document_brochure_DFN1412__diodes_transistors.pdf DFN1412-6 - a new (double) package standard Brochure 2022-09-21

Marcom graphics (1)
文件名稱 標題 類型 日期
DFN1006B-3_SOT883B_mk.png plastic, leadless ultra small plastic package; 3 solder lands; 0.35 mm pitch; 1 mm x 0.6 mm x 0.37 mm body Marcom graphics 2017-01-28

Selection guide (1)
文件名稱 標題 類型 日期
Nexperia_Selection_guide_2023.pdf Nexperia Selection Guide 2023 Selection guide 2023-05-10

White paper (1)
文件名稱 標題 類型 日期
Nexperia_document_whitepaper_RET_devices_2021.pdf Nexperia document whitepaper RET devices 2021 White paper 2022-09-21

如果您有支持方面的疑問，請告知我們。如需獲得設計支持，請告知我們并填寫應答表，我們會盡快回復您。

或聯系我們獲得進一步支持。


Frequently Asked Questions

A RET is a Resistor Equipped Transistor. RETs combine the bias resistor and bias-emitter resistor in the same package as the transistor. Double RETs are devices that combine two transistors and two matching bias resistors and bias-emitter resistors.

Transistors and resistors are combined in one package. This

  • saves space
  • reduces pick and place costs
  • offers additional option for circuit design
  • reduces bom costs


Resistor equipped transistors (RETs) are also known as:

  • Digital transistors
  • Pre-Bias transistors
  • Built in resistor bipolar transistors

RETs can be used in:

  • Low side switch
  • High side switch
  • Push pull stage

RETs are suitable for use in numerous applications including:

  • Automotive
  • Industrial and Power
  • Communication
  • And many more

Nexperia offers more than 400 parts to chose from including:

  • 50 V RETs with 100 mA
  • 50 V RETs with 500 mA
  • 80 V RETs with 100 mA
  • 40 V with 600mA Low VCEsat RETs (Performance based RETs (PBR))

Within Nexperia’s RET portfolio you will find single and dual RETs with a great variety of resistor combinations.

Nexperia RETs are available in a wide range of leaded and leadless SMD packages:
Standard leaded SMD packages like SOT23, SOT323, SOT457, SOT223 as well as leadless SMD packages like the very small DFN1006-3 and DFN packages with side-wettable flanks like DFN1110D-3 and DFN1412D-3

Most of our products are qualified to AEC-Q101, please always check the datasheet.

A voltage swing of approx. 1.2 V is sufficient for switching the RET. Therefore, RETs can be easily driven directly by a micro controller.

Nexperia RETs have a state-of-the-art ratio tolerance of down to +-10% (PBR)


Nexperia is offering 80 V RETs that provide enough headroom for use in 48 V automotive board net (e.g. mild hybrid and EV cars) and other higher voltage circuits which are often subject to large spikes and pulses that previous 50 V parts cannot handle. The new series (NHDTx and NHUMx) includes 42 parts with PNP / NPN combinations. These come with the same bias resistor combinations as Nexperia’s 50 V parts. Devices have a 100 mA current capability and are AEC-Q101-approved.

交叉參考
